A design introduced by Hackaday features a glue-in filament hinge that simplifies 3D printed hinge creation. It allows separate printing of hinge parts and captive filament pins, offering a new approach for makers and designers.

Hackaday has unveiled a new 3D printing hinge design that uses a glue-in filament hinge, offering a practical alternative to traditional integrated hinges for makers and designers.

Before you orderOffer from Amazon

Get furniture and decor delivered free with Prime

  • Fast, free delivery on millions of items
  • Prime Video, Amazon Music and more included
  • Member-only deals all year
Start your free Prime trial Free trial for eligible customers · Cancel anytime
As an affiliate, we earn on qualifying purchases.

The design involves printing a hinge component separately as a U-shaped piece, which is then glued into the main object after printing. This approach addresses common issues with print orientation and hinge functionality. The hinge pin is a 1.75 mm filament that is held captive within the hinge after assembly, eliminating the need for gluing or inserting separate pins.

Alex Krush, who developed the design, provides the parts in STEP format, facilitating CAD modifications and integration into various projects. The design aims to simplify hinge creation in 3D printing, especially for complex or multi-orientation objects, by separating the hinge from the main print and using filament as a captive pin.

Advantages for 3D Printing and Maker Projects

This new glue-in hinge design could significantly impact 3D printing by simplifying hinge assembly, reducing print orientation constraints, and improving hinge durability. It offers a practical solution for makers who need reliable, easy-to-assemble hinges in their designs without complex post-processing or multiple print orientations. The captive filament pin also enhances hinge stability and ease of assembly, making it appealing for hobbyists and professionals alike.
